SD534 Plummer block housing
SD534 Plummer block housing detail Specifications:
Housing material : gray cast iron or ductile iron
SD series pillow block housing suitable for spherical roller bearings and adaptor sleeve mounting
Bearing No. : 22234K
Adaptor sleeve : H3134
Locating Ring:
1pcs of SR310X10
Weight : 105 kg
Main Dimensions:
Shaft Dia (di) : 150 mm
D (H8) : 310 mm
Overall Length (a) : 620 mm
Overall Width (b) : 230 mm
Foot height (c) : 60 mm
Width of bearing seat (g H12) : 106 mm
Distance shaft axis (h h12) : 180 mm
Width (L) : 270 mm
Foot height (W) : 360 mm
Bolt Hole Centres (m) : 510 mm
n : 140 mm
Width of attachment bolt hole (u) : 36 mm
Length of attachment bolt hole (V) : 52 mm
Size of cap bolt (s) : M30
Diameter sealing (d2 H12) : 153 mm
Diameter sealing groove (d3 H12) : 183 mm
F1 (H13) : 10 mm
f2 : 13.8 mm
